4g63t v.s. 6a13tt?

Mitsu Lancer, Evo, GSR, MIVEC, 4G**, GDI, Galant, Outlander, L200 Sportero/Triton etc.

Moderator: 3ne2nr Mods

Grip
Ricer
Posts: 17
Joined: June 29th, 2009, 2:50 pm

4g63t v.s. 6a13tt?

Postby Grip » June 30th, 2009, 3:56 pm

Thinking about doing a vr4 conversion on my galant vrg, however it was suggested that I use a 4g63t instead of the 6a13dett. I want to know what are the advantages and disadvantages to both swaps also the costs associated with them.

Advertisement
User avatar
xtech
18 pounds of Boost
Posts: 2417
Joined: March 15th, 2006, 2:01 pm
Contact:

Postby xtech » June 30th, 2009, 6:22 pm

main disadvantage is the the price............you can get 2 6A13tt complete in front cuts for the price of one 4G63T on the ground and you still need rear suspension parts from a VR4.



So which engine is better, while it is true that the 4G63T has a lot more aftermarket parts letting you push to 500hp or more fairly easily, nothing like that exists for the 6A13. For most folks 280-350hp range is enough for some fun driving so I don't see a reason to even consider the 4G63T. A full exhaust including downpipes and increased boost will see you to over 320hp very easily, add an intercooler and a fuel controller and you'll be at 340-350hp.

The V6 is an amazingly smooth engine with no harsh explosive power and vibrations at any point in the rev range and it loves being anywhere between 1500rpm and 7000rpm with virtually no turbo lag at all.

Anybody here who has ever got a ride in an EVO knows that below 3000rpm they feel like a normal 4G93 1.8L 4 cylinder. But from 3500 to 7000rpm they explode to life and feel just like a 6A13TT, not some super special amazing engine ent?

The EVO 9 and X are rated at about 215kw and 400nm of torque, a 6A13TT will get over that amount just by increasing boost to 12-14psi with a cheap manual boost controller. Without changing the turbo a 4G63T is limited to about the same sort of power levels as a VR4.

As far as I can see the only advantage of going with a 4G63 is that you can buy manifolds and turbos that will let you get to 500hp or more straight off the shelf. However that will cost most folks an arm an a leg to buy an thats after paying for the EVO engine with your 1st born and a left kidney :shock:

So far the only people who have put 4G63's into 8G's are the Americans and thats because they cant find 6A13TT.
:lol: :lol: :lol:

User avatar
secret_service
3NE 2NR for life
Posts: 144
Joined: July 1st, 2009, 6:52 am
Location: Thats Classified
Contact:

Postby secret_service » July 2nd, 2009, 2:22 pm

Engine Calculator v 1.2 ......>>>>> http://tpizza.110mb.com/ecv1_2.htm
This page will calculate lots of values for an engine configuration that you enter. This is useful for determining the size of turbos, injectors, exhaust piping, intercooler piping, etc. It also gives you an idea of what affect better heads (better Volumetric Effiency), higher boost pressure and other factors have on horse power output. Values by default are for 6a13 2.5L V6 24V DOHC Engine. 8G Mitsubishi Legnum VR-4(ec5w) or Galant VR-4(ec5a).

Grip
Ricer
Posts: 17
Joined: June 29th, 2009, 2:50 pm

Postby Grip » July 2nd, 2009, 3:12 pm

Thanks for the info. What about fuel economy and weight to power?

User avatar
secret_service
3NE 2NR for life
Posts: 144
Joined: July 1st, 2009, 6:52 am
Location: Thats Classified
Contact:

Postby secret_service » July 2nd, 2009, 3:56 pm

Grip wrote:Thanks for the info. What about fuel economy and weight to power?


economy and speed.........is like oil an water.
The VR-4 was fitted with a V6TT because the engineers figured out the maths

A heavy Galant need more torque to move. :lol:

User avatar
honda hoe
TriniTuner 24-7
Posts: 8170
Joined: May 31st, 2006, 11:39 am
Location: polishing my "Most Banned In '07" trophy

Postby honda hoe » July 2nd, 2009, 9:32 pm

a vrg is a heavy car

i think u better off woth the 6A

User avatar
A.W.O.L
3NE2NR is my LIFE
Posts: 862
Joined: September 5th, 2008, 12:37 pm
Location: ....souping it up..

Postby A.W.O.L » July 2nd, 2009, 10:36 pm

yeah u better off wit the V6..

User avatar
Rooki3
TriniTuner 24-7
Posts: 7295
Joined: December 18th, 2008, 10:52 pm

Postby Rooki3 » July 3rd, 2009, 12:17 am

6A13TT all the way
stock for stock...........you'll be able to destroy all sorts
HOLD DAT!!
<embed src="http://www.youtube.com/v/yD7FokvTalQ&hl=en&fs=1&" type="application/x-shockwave-flash" allowscriptaccess="always" allowfullscreen="true" width="425" height="344"></embed>

Trinitim
Street 2NR
Posts: 35
Joined: October 6th, 2008, 1:25 pm
Location: Gasparillo, South Trinidad
Contact:

Postby Trinitim » July 3rd, 2009, 11:45 am

v6 power all the way body I have one absolutely wonderful.

Trinitim
Street 2NR
Posts: 35
Joined: October 6th, 2008, 1:25 pm
Location: Gasparillo, South Trinidad
Contact:

Postby Trinitim » July 3rd, 2009, 11:46 am

Sorry buddy not body my bad watching the cricket here LOL!!!

User avatar
xtech
18 pounds of Boost
Posts: 2417
Joined: March 15th, 2006, 2:01 pm
Contact:

Postby xtech » July 5th, 2009, 7:29 pm

is the hyundai tiburon using a stroked 2.7l 6A13 and calling it V6 Delta ?
I say it is because it is an aluminum block not a cast iron like the 6G72

http://www.korea-racers.de/elantra/v6swap/index_en.html

i was poking around in the overseas hyundai forums since a fellow tuner here wanted to swap a 6A13TT in a '96 Elantra frame. But most of the folks over seas who have done it used the Tiburon motor. It looks like it is using 1995 mitsu 6a12 technology with no coil packs



User avatar
QG
punchin NOS
Posts: 3553
Joined: July 18th, 2006, 9:56 pm
Location: South

Postby QG » July 6th, 2009, 11:44 am

63T ftw :mrgreen:


Go with the Mivec Turbo 63T, and tune from there.

Grip
Ricer
Posts: 17
Joined: June 29th, 2009, 2:50 pm

Postby Grip » July 8th, 2009, 2:57 pm

What about the 6g72 twin turbo engine from the GTO?

User avatar
geodude
Riding on 18's
Posts: 1777
Joined: February 21st, 2009, 1:22 am
Location: Hiding from the Chuna spelling police
Contact:

Postby geodude » July 11th, 2009, 9:03 am

lots of info out there however i beleive that the 6a13tt is the better suited engine for your application, i want one so badly,

these things are the sheit. :lol:

jusjase44
3NE 2NR for life
Posts: 110
Joined: October 17th, 2005, 12:30 am
Location: Chaguanas
Contact:

Postby jusjase44 » August 18th, 2009, 8:45 pm

What is the latest Grip?

User avatar
7143
Chronic TriniTuner
Posts: 623
Joined: December 4th, 2008, 9:46 am
Location: conquering the pothole solodex

Postby 7143 » August 23rd, 2009, 8:06 pm

jusjase44,no reply like the man give up..... :faint: from all the stress,headache and buss pocket from the swap.....but is still 63 ftw.....

jusjase44
3NE 2NR for life
Posts: 110
Joined: October 17th, 2005, 12:30 am
Location: Chaguanas
Contact:

Postby jusjase44 » August 23rd, 2009, 9:07 pm

well it look so i am in the middle of a swap myself 4G93GDI on AWD chassis to 6A13TT, been lookin for some advice but no luck so far

User avatar
MISHI
3NE 2NR Aficionado
Posts: 5384
Joined: May 14th, 2003, 4:00 pm
Location: Location: Location!
Contact:

Postby MISHI » August 23rd, 2009, 9:41 pm

Bolt for bolt, it will be easier to install the VR4 system 6A13TT. but whether you look at it one way or the other, it's expensive. Don't discount the 63T because of it's price though... in the longer run, it may actually cost you less to run.

And the main reason is accessibility to parts... OEM or aftermarket. You will faster get parts for a 63T than the V6 and quite possibly much cheaper too. The engine is capable of making loads of power with the right tuning/ build.

But if it's bolt for bolt and you can source your parts with a reasonable price, the 6A13 is a great engine.

Grip
Ricer
Posts: 17
Joined: June 29th, 2009, 2:50 pm

Postby Grip » October 25th, 2009, 1:58 am

GOT SOME BAD NEWS
I HAD TO SCRAP THE PROJECT.

User avatar
geodude
Riding on 18's
Posts: 1777
Joined: February 21st, 2009, 1:22 am
Location: Hiding from the Chuna spelling police
Contact:

Postby geodude » October 28th, 2009, 5:51 am

Bad news also i may need to starty my project ASAP as my 4G93 smoking real bad, so i am in the market for a 6A13TT, but i intend to run it FWD, so sorry i didnt take the engine from Xtech, so i am looking for options let me know what you guys have and what price range it may cost, if i get an entire front cut i might take it as it would save a lot of headacke later on i was told. but price is an issue so the more options the better

thanks

hmph
Chronic TriniTuner
Posts: 543
Joined: November 21st, 2007, 5:28 pm

Postby hmph » October 28th, 2009, 10:30 am

4g63t hands down.

User avatar
CS3A_GLX
I LUV THIS PLACE
Posts: 1027
Joined: July 19th, 2010, 5:58 pm
Location: In Your Dreams

Re: 4g63t v.s. 6a13tt?

Postby CS3A_GLX » October 3rd, 2010, 10:38 am

hey guys. can a 6a13tt fit in a cedia lancer?

User avatar
smithbn187
Riding on 13's
Posts: 8
Joined: October 30th, 2010, 5:53 pm
Location: 1 GEAR IN FRONT OF YOU

Re: 4g63t v.s. 6a13tt?

Postby smithbn187 » November 29th, 2010, 10:27 pm

6A13TT

User avatar
thingcall
Street 2NR
Posts: 55
Joined: September 27th, 2008, 11:23 pm
Location: Tobago

Re: 4g63t v.s. 6a13tt?

Postby thingcall » March 22nd, 2011, 12:27 am

Grip wrote:Thinking about doing a vr4 conversion on my galant vrg, however it was suggested that I use a 4g63t instead of the 6a13dett. I want to know what are the advantages and disadvantages to both swaps also the costs associated with them.


Ok so i was watching an reading what going on an it so happen that i was thinking of putting a 4g63t in this galant but base on what response i saw going wit d 6a13tt engine an looking for a l.s.d f.w.d box to go wit it, anybody could point me in d right direction price wise too?
Attachments
garage stuff 019.png
garage stuff 019.png (383.31 KiB) Viewed 11558 times

User avatar
CS3A_GLX
I LUV THIS PLACE
Posts: 1027
Joined: July 19th, 2010, 5:58 pm
Location: In Your Dreams

Re: 4g63t v.s. 6a13tt?

Postby CS3A_GLX » March 22nd, 2011, 1:07 am

budget at least 10k for engine n tranny for the 6a13tt and 5k for the suspension setup yadda yadda...

if its the 4g63t u after, well...hope yuh pockets a bit deeper!



refer at 3.12 for 6a13tt powaaa!

User avatar
thingcall
Street 2NR
Posts: 55
Joined: September 27th, 2008, 11:23 pm
Location: Tobago

Re: 4g63t v.s. 6a13tt?

Postby thingcall » March 23rd, 2011, 11:25 am

on average how much to put-in wire up and stuff.

User avatar
suzieboy
3NE 2NR for life
Posts: 137
Joined: February 21st, 2007, 11:55 pm
Location: ON the shoulder...

Re: 4g63t v.s. 6a13tt?

Postby suzieboy » March 24th, 2011, 12:23 pm

^^well that kinda depends on the state of ur harness but roughly between 1k-2k.

User avatar
living louder
Street 2NR
Posts: 73
Joined: November 17th, 2008, 8:21 pm

Re: 4g63t v.s. 6a13tt?

Postby living louder » April 8th, 2011, 7:36 am

lol @ video

User avatar
gallantpan
Sweet on this forum
Posts: 273
Joined: January 3rd, 2007, 3:33 pm
Location: San Fernando
Contact:

Re: 4g63t v.s. 6a13tt?

Postby gallantpan » April 8th, 2011, 9:44 am

living louder wrote:lol @ video

x2, lol@ fizzgig also. :P

ecktt
Street 2NR
Posts: 95
Joined: March 23rd, 2009, 7:18 am

Re: 4g63t v.s. 6a13tt?

Postby ecktt » April 27th, 2011, 6:53 pm

I'd got with a 4G63T if only because a lot of work has been done on reverse engineering the ECU giving you plenty options to tune. The 6a13tt might be tunable but haven't seen any info on it.
